Data Structures |
| struct | ci_tune_service_info |
| struct | ci_tune_del_sys_desc |
| struct | ci_operator_nit |
| struct | ci_host_info |
| struct | ci_operator_info |
| struct | ci_operator_search |
| struct | ci_licence_update |
| struct | ci_query_param |
| struct | S_CIP_RELEASE_REPLY |
Defines |
|
#define | CIP_NO_CI_SCREEN 0 |
|
#define | CIP_CI_MENU_LIST_SCREEN 1 |
|
#define | CIP_CI_ENQUIRY_SCREEN 2 |
|
#define | CIP_URI_LEN 8 |
|
#define | CIP_CICAM_ID_LEN 8 |
|
#define | CIP_MAX_PIN_LENGTH 8 |
|
#define | CIP_PIN_PRIVATE_DATA_SIZE 15 |
|
#define | CIP_SERVICE_TYPE_TV 0x00000001 /* MPEG2 TV */ |
|
#define | CIP_SERVICE_TYPE_RADIO 0x00000002 /* MPEG1 Layer-II radio */ |
|
#define | CIP_SERVICE_TYPE_TELETEXT 0x00000004 /* Teletext */ |
|
#define | CIP_SERVICE_TYPE_AVC_RADIO 0x00000008 /* AVC radio */ |
|
#define | CIP_SERVICE_TYPE_DATA 0x00000010 /* Data */ |
|
#define | CIP_SERVICE_TYPE_HD_TV 0x00000020 /* MPEG2 HD TV */ |
|
#define | CIP_SERVICE_TYPE_AVC_SD_TV 0x00000040 /* AVC SD TV */ |
|
#define | CIP_SERVICE_TYPE_AVC_HD_TV 0x00000080 /* AVC HD TV */ |
|
#define | CIP_DELIVERY_TYPE_DVBT 0x0001 |
|
#define | CIP_DELIVERY_TYPE_DVBT2 0x0002 |
|
#define | CIP_DELIVERY_TYPE_DVBC 0x0004 |
|
#define | CIP_DELIVERY_TYPE_DVBC2 0x0008 |
|
#define | CIP_DELIVERY_TYPE_DVBS 0x0010 |
|
#define | CIP_DELIVERY_TYPE_DVBS2 0x0020 |
|
#define | CIP_APP_TYPE_MHEG 0x0001 |
|
#define | CIP_APP_TYPE_HBBTV 0x0002 |
|
#define | CIP_APP_TYPE_OIPF 0x0004 |
|
#define | CIP_START_OPERATOR_SEARCH_NO 0x00 |
|
#define | CIP_START_OPERATOR_SEARCH_YES 0x01 |
|
#define | CIP_START_OPERATOR_SEARCH_ASK 0x02 |
|
#define | CIP_RECORD_MODE_WATCH_AND_BUFFER 0x00 |
|
#define | CIP_RECORD_MODE_TIMESHIFT 0x01 |
|
#define | CIP_RECORD_MODE_UNATTENDED 0x02 |
|
#define | CIP_LICENCE_STATUS_OK 0x00 |
|
#define | CIP_LICENCE_STATUS_NO_ENTITLEMENT 0x01 |
|
#define | CIP_LICENCE_STATUS_UNDEFINED_ERROR 0x02 |
|
#define | CIP_LICENCE_STATUS_RIGHTS_EXPIRED 0x03 |
|
#define | CIP_LICENCE_STATUS_PLAY_COUNT_EXCEEDED 0x04 |
|
#define | CIP_LICENCE_STATUS_RETENTION_LIMIT_EXCEEDED 0x05 |
|
#define | CIP_LICENCE_STATUS_INVALID_LICENCE 0x06 |
|
#define | CIP_LICENCE_RECEIVED_OK 0x00 |
|
#define | CIP_LICENCE_RECEIVED_INVALID_DATA 0x01 |
|
#define | CIP_LICENCE_RECEIVED_HOST_ERROR 0x02 |
|
#define | CIP_CAM_PIN_CODE_WRONG 0 |
|
#define | CIP_CAM_PIN_CAM_BUSY 1 |
|
#define | CIP_CAM_PIN_CODE_CORRECT 2 |
|
#define | CIP_CAM_PIN_CODE_UNCONFIRMED 3 |
|
#define | CIP_CAM_PIN_NO_VIDEO_BLANK 4 |
|
#define | CIP_CAM_PIN_CONTENT_STILL_SCRAMBLED 5 |
Typedefs |
|
typedef struct ci_tune_service_info | S_CIP_TUNE_SERVICE_INFO |
|
typedef struct ci_tune_del_sys_desc | S_CIP_TUNE_DEL_SYS_DESC |
|
typedef struct ci_operator_nit | S_CIP_OPERATOR_NIT |
|
typedef struct ci_host_info | S_CIP_HOST_INFO |
|
typedef struct ci_operator_info | S_CIP_OPERATOR_INFO |
|
typedef struct ci_operator_search | S_CIP_OPERATOR_SEARCH |
|
typedef struct ci_licence_update | S_CIP_LICENCE_UPDATE |
|
typedef struct ci_query_param | S_CIP_QUERY_PARAM |
|
typedef U32BIT(* | F_CIP_CALLBACK )(S_CIP_QUERY_PARAM *) |
Enumerations |
| enum | E_CI_QUERY {
CIPLUS_GET_COUNTRY_CODE,
CIPLUS_GET_LANGUAGE_CODE,
CIPLUS_TUNE_TO_SERVICE,
CIPLUS_TUNE_DEL_SYS_DESC,
CIPLUS_CAM_UPGRADE_OPTION,
CIPLUS_REQUEST_HOST_CONTROL,
CIPLUS_RELEASE_HOST_CONTROL,
CIPLUS_PROCESS_NIT,
CIPLUS_REQUEST_HOST_INFO,
CIPLUS_OPERATOR_TUNE,
CIPLUS_REQUEST_OPERATOR_SEARCH,
CIPLUS_OPERATOR_CAM_AVAILABLE,
CIPLUS_OPERATOR_CAM_REMOVED,
CIPLUS_GET_SUBTITLES_STARTED,
CIPLUS_STOP_SUBTITLES,
CIPLUS_START_SUBTITLES
} |
| enum | E_CIP_SLOT_STATUS {
CIP_SLOT_STATUS_UNKNOWN = 0x0000,
CIP_SLOT_STATUS_MODULE_READY = 0x0001,
CIP_SLOT_STATUS_CA_USED = 0x0002,
CIP_SLOT_STATUS_CAS_SUPPORTED = 0x0004,
CIP_SLOT_STATUS_CI_PLUS_MODULE = 0x0008,
CIP_SLOT_STATUS_SERVICE_ALLOWED = 0x0010
} |
| enum | E_CIP_TUNE_STATUS {
CIP_TUNER_LOCKED,
CIP_TUNER_NOTLOCKED,
CIP_TUNER_BUSY,
CIP_TUNER_UNSUPPORTED_SYSTEM,
CIP_TUNER_BAD_PARAM,
CIP_TUNER_SERVICE_NOT_FOUND,
CIP_TUNER_UNDEFINED_ERROR
} |
| enum | E_CIP_OPERATOR_SEARCH_REQUEST_TYPE { CIP_OPERATOR_SEARCH_DEFERRED,
CIP_OPERATOR_SEARCH_IMMEDIATE,
CIP_OPERATOR_SEARCH_SCHEDULED
} |
Functions |
|
void | CIP_OpenEngine (F_CIP_CALLBACK callback) |
| | Open CIPLUS engine. Must be called before any other CIPLUS related function.
|
| void | CIP_EnterCIMenu (U8BIT slot_id) |
| | Enter CI menu.
|
| U8BIT * | CIP_GetCIModuleName (U8BIT slot_id) |
| | Returns a pointer to the string containing the name of the module.
|
| U8BIT | CIP_GetCIScreenType (U8BIT slot_id) |
| | Returns the screen type required, and also copies the required data into the current data for access by the application.
|
| U8BIT * | CIP_GetCIMenuScreenTitle (U8BIT slot_id) |
| | Return a pointer to the menu/list screen title string.
|
| U8BIT * | CIP_GetCIMenuScreenSubtitle (U8BIT slot_id) |
| | Returns a pointer to the menu/list screen subtitle string.
|
| U8BIT | CIP_GetCIMenuScreenNumItems (U8BIT slot_id) |
| | Return the number of items on the menu/list screen.
|
| U8BIT * | CIP_GetCIMenuScreenItemText (U8BIT slot_id, U8BIT item) |
| | Return a pointer to the string for the specified item on the menu/list screen.
|
| U8BIT * | CIP_GetCIMenuScreenBottomText (U8BIT slot_id) |
| | Returns a pointer to the menu/list screen bottom text string.
|
| void | CIP_SetCIMenuScreenResponse (U8BIT slot_id, U8BIT response) |
| | Send the response to the menu screen to the module.
|
| U8BIT * | CIP_GetCIEnquiryScreenText (U8BIT slot_id) |
| | Returns a pointer to the enquiry screen text string.
|
| U8BIT | CIP_GetCIEnqScreenHideResponse (U8BIT slot_id) |
| | Returns a value indicating whether the user response text should be hidden (e.g. pin number) or not.
|
| U8BIT | CIP_GetCIEnqScreenResponseLength (U8BIT slot_id) |
| | Return the length of the required user response text.
|
| void | CIP_SetCIEnquiryScreenResponse (U8BIT slot_id, U8BIT ok_cancel, U8BIT *response_str_ptr) |
| | sends a message to the CI+ stack to indicate the response to the enquiry screen
|
| U8BIT | CIP_GetCIScreenCloseDelay (U8BIT slot_id) |
| | Return the delay required before closing the CI screen.
|
| void | CIP_CloseCIScreen (U8BIT slot_id) |
| | Called by the application to close the MMI session.
|
| void | CIP_SetHostCountryCode (U32BIT code) |
| | Set the Host Country code.
|
| void | CIP_SetHostLanguageCode (U32BIT code) |
| | Set the Host Language code.
|
| void | CIP_SetDisplayCharacterTables (U8BIT *tables, U16BIT len) |
| | Sets the display character tables supported by the receiver. The tables are provided as a single string containing the prefix byte(s) of encoded text strings as defined in annex A.2 of ETSI EN 300 468. For example, if ISO/IEC 8859-7 is supported by the receiver, then text strings starting with 0x03 and with 0x10 0x00 0x07 are supported. In this case the string would be "\x03\x10\x00\x07".
|
| void | CIP_SetInputCharacterTables (U8BIT *tables, U16BIT len) |
| | Sets the input character tables supported by the receiver. The tables are provided as a single string containing the prefix byte(s) of encoded text strings as defined in annex A.2 of ETSI EN 300 468. For example, if ISO/IEC 8859-7 is supported by the receiver, then text strings starting with 0x03 and with 0x10 0x00 0x07 are supported. In this case the string would be "\x03\x10\x00\x07".
|
| U16BIT | CIP_GetSlotStatus (U8BIT slot_id, U8BIT *pmt, U8BIT *ci_protection_descriptor) |
| | Return status of CI slot.
|
| BOOLEAN | CIP_IsConditionalAccessUsed (U8BIT *pmt) |
| | Tell whether conditional access is used in the service.
|
| void | CIP_ReportPmt (U8BIT slot_id, U8BIT *pmt) |
| | Report PMT to CI stack.
|
| void | CIP_GetUsageRulesInfo (U8BIT slot_id, U16BIT service_id, U8BIT uri[CIP_URI_LEN]) |
| | Return the current URI for the given service.
|
| void | CIP_GetDefaultUsageRulesInfo (U8BIT raw_uri[CIP_URI_LEN]) |
| | Sets the default URI values into the given array. The URI requires HDCP.
|
| void | CIP_UpdateUsageRules (U8BIT orig_uri[CIP_URI_LEN], U8BIT new_uri[CIP_URI_LEN]) |
| | Update packed URI given a new packed URI.
|
| U32BIT | CIP_GetRetentionLimit (U8BIT uri[CIP_URI_LEN]) |
| | Return the retention limit given a packed URI.
|
| void | CIP_ApplyUsageRulesInfo (U8BIT *uri) |
| | Apply the given Usage Rules Information.
|
| void | CIP_ApplyUsageRulesInfoForPlayback (U8BIT *uri) |
| | Apply the given Usage Rules Information for playback.
|
| void | CIP_ApplyCCKeys (U8BIT path) |
| | Apply stored CC keys (if any) on given path.
|
| void | CIP_ClearCCKeys (U8BIT path) |
| | Clear CC keys (if any) from given path.
|
| BOOLEAN | CIP_IsHDCPRequired (U16BIT service_id) |
| | Tell whether the given service requires HDCP.
|
|
void | CIP_AppStopped (void) |
| | Should be called to notify CI+ that the running MHEG app has been stopped.
|
| U8BIT | CIP_GetSlotIdForModule (U32BIT module) |
| | Returns the slot id for the given module handle.
|
| BOOLEAN | CIP_TuneReply (U8BIT path, U32BIT module, E_CIP_TUNE_STATUS status) |
| | Called by the host to send the status of the tune operation to the module.
|
| BOOLEAN | CIP_AskRelease (U32BIT module) |
| | Called by the host to ask the module to restore replaced PIDs and close the host control session.
|
| BOOLEAN | CIP_RequestOperatorStatus (U32BIT module) |
| | Called by the host to request changing to an operator profile.
|
| BOOLEAN | CIP_OperatorExit (void) |
| | Request the current operator module to exit operator profile.
|
| BOOLEAN | CIP_StartOperatorSearch (U32BIT module) |
| | Called by the app to start an operator profile search that has been requested.
|
| void | CIP_SetRecordOperatingMode (U8BIT slot_id, U8BIT mode, U16BIT service_id) |
| | Sets the record operating mode for the given slot id.
|
| BOOLEAN | CIP_SendRecordStart (U8BIT slot_id, U16BIT program_number, U8BIT *pin_string) |
| | Called by the app when a recording is to be started on a CA protected service.
|
| BOOLEAN | CIP_SendRecordStop (U8BIT slot_id) |
| | Called by the app when a recording is stopped or completes.
|
| BOOLEAN | CIP_SendPlaybackLicence (U8BIT slot_id, U16BIT program_number, U8BIT *licence, U16BIT licence_len) |
| | Sends a CICAM licence to a module during playback, which will result in a modified licence being notified through STB_CINotifyCicamLicence.
|
| U8BIT * | CIP_GetRecordingLicence (U8BIT slot_id, U8BIT *licence_status, U16BIT *licence_len, U8BIT raw_uri[CIP_URI_LEN]) |
| | Returns the last licence received from the CAM when recording.
|
| U8BIT * | CIP_GetPlaybackLicence (U8BIT slot_id, U8BIT *licence_status, U16BIT *licence_len, U8BIT raw_uri[CIP_URI_LEN]) |
| | Returns the last licence received from the CAM during playback.
|
| void | CIP_SendCicamLicenceStatus (U8BIT slot_id, U32BIT status) |
| | Must be called after a licence has been supplied during recording or playback to inform the CAM that the licence has been handled.
|
| BOOLEAN | CIP_GetCicamId (U8BIT slot_id, U8BIT cicam_id[8]) |
| | Returns the CICAM identifier for the given slot.
|
| U8BIT | CIP_FindSlotForCicamId (U8BIT cicam_id[8]) |
| | Checks CAMs in all slots to find the one with the given CAM id.
|
| BOOLEAN | CIP_CheckCicamPin (U8BIT slot_id, U8BIT *pin_data) |
| | Called by the host to check whether a CAM pin is valid. An STB_EVENT_CI_PIN_STATUS event will be sent to notify the host of the validity, or otherwise, of the pin.
|
| BOOLEAN | CIP_GetRecordingPinInfo (U8BIT slot_id, U8BIT *status, U8BIT *age_rating, U8BIT **private_data, U16BIT *date_code, U8BIT *hour, U8BIT *min, U8BIT *sec) |
| | Returns the information to be stored with a pin event when recording.
|
| BOOLEAN | CIP_SendPinPlayback (U8BIT slot_id, U8BIT age_rating, U8BIT *private_data) |
| | Sends a pin event to the CAM during playback.
|
